Support GPU length up to 435 mm
Support CPU cooler height up to 157 mm
Support installing of up to 10 x 120 mm fans
Curved tempered glass creates a seamless view for your best-in-class hardware
Black
MODEL
UV7
STRUCTURE DIMENSIONS (L x W x H)
413 x 277 x 410 mm
PRODUCT DIMENSIONS (L x W x H)
452 × 277 x 436 mm
PACKAGE DIMENSIONS (L x W x H)
485 x 340 x 490 mm
STRUCTURE THICKNESS
0.6 mm
MATERIALS
SPCC, tempered glass, plastic
FORM FACTOR
ATX / M-ATX / ITX
3.5" HDD: 2 + 2.5" SSD: 3
CPU MAX HEIGHT
157 mm
VGA MAX LENGTH
435 mm
I/O PANEL
USB 3.0 x 2 + Type-C x 1 + HD AUDIO
PCI CARD SLOT
7
FAN SUPPORT
Side: 3 x 12 cm
Top: 3 x 12 cm
Rear: 1 x 12 cm
Bottom: 3 x 12 cm
LIQUID COOLING SUPPORT
Top: 360 mm , Side: 360 mm
POWER SUPPLY SUPPORT
Bottom mounted (200 mm)
WEIGHT
N.W.: 6.52 kg
G.W.: 7.93 kg
