Support GPU length up to 320 mm
Support CPU cooler height up to 155 mm
Support installing of up to 7 x 120 mm fans
Support 240 mm radiators on the top and side panels
Front and side panoramic tempered glass panels,designed to deliver an uninterrupted wide-angle view of your components
Magnetic-mount dust filter on the top and bottom for easy maintenance
*Computer parts are not included. Cooling fan may vary among different countries/regions.
Black
MODEL
BV5
STRUCTURE DIMENSIONS (L x W x H)
335 × 270 × 350 mm
PRODUCT DIMENSIONS (L x W x H)
340 × 270 × 375 mm
PACKAGE DIMENSIONS (L x W x H)
420 x 340 × 415 mm
STRUCTURE THICKNESS
0.5 mm
MATERIALS
SPCC, tempered glass, plastic
FORM FACTOR
M-ATX / ITX
3.5" HDD: 1 + 2.5" SSD: 2
CPU MAX HEIGHT
155 mm
GPU MAX LENGTH
320 mm
I/O PANEL
USB 3.0 x 1 + USB 2.0 x 2 + HD Audio
PCI CARD SLOT
4
FAN SUPPORT
Top: 2 x 120 mm
Bottom: 2 x 120 mm
Rear: 1 x 120 mm
Side: 2 x 120 mm
LIQUID COOLING SUPPORT
Top: 240 mm
Side: 240 mm
POWER SUPPLY SUPPORT
Bottom mounted (170 mm)
WEIGHT
N.W.: 3.4 kg ± 10%
G.W.: 4.3 kg ± 10%
