Liquid Cooling Support(Fans are Optional) TOP：24cm
Fans Support: Up to 8 fans
USB3.0*1+USB2.0*1+HD AUDIO
5.25" CD ROM: 0
①3.5" HDD: 2+2.5" SSD: 2
②3.5" HDD: 1+2.5" SSD: 3
LEFT & RIGHT SIDE PANEL:TEMPERED GLASS
*Computer parts are not included / Cooling fan may distinctively from diferent regions/countries
Model
B3-M
Structure Dimensions(L*W*H)
350*195*435MM
Product Dimensions(L*W*H)
385*195*447MM
Package Dimensions(L*W*H)
490*240*450MM
Structure Thickness
0.45MM
Materials
SPCC 0.45MM
LEFT SIDE PANEL: TEMPERED GLASS
Form Factor
M-ATX/ITX
5.25" CD ROM: 0
①3.5" HDD: 2 + 2.5" SSD: 2
②3.5" HDD: 1 + 2.5" SSD: 3
CPU MAX Height
160MM
VGA MAX Length
340MM
I/O Panel
USB2.0*2+USB3.0*1+ HD AUDIO
PCI Card Slot
5
Fan Support
FRONT : 3*12CM
TOP : 2*12CM
REAR : 1*12CM
BOTTOM : 2*12CM
Liquid Cooling Support
FRONT:360MM/240MM
TOP:240MM
Power Supply Support
Weight
N.W.: 4.09KG G.W.: 4.84KG
